型号：四眼观众灯

所属系列：面光灯系列

扫描二维码咨询

电话：13078886936/刘经理

产品参数

四眼观众灯
XL-GZD04
1.额定电压：AC110V～240V,50～60Hz
2.功率:450W
3.光源：4*100W LED/平均寿命：50000H
4.色温校正：3200K～5600K线性调节
5.透镜角度：25°
6.发光角度：可手动调节角度
7.频闪：独立电子频闪1-25Hz，可随机频闪，脉冲频闪，同步异步频闪，单色、混色温频闪
8.混色：单色无，双色WY混色（0-100%饱和度可调），内置宏功能
9.电子调光：0-100%独立电子线性调光，摄像视频真实无闪烁，主从自走自动同步功能，控台正常控制自走永久同步
10.数码显示菜单：调用各种场景，内置程序可以直接调用执行
11.控制模式：多种声控、DMX512、内置程序自走、主从联机模式
12.通道：12通道
13.灯具连接：三芯信号线IN/OUT 电源线IN/OUT
14.特点：铸铝外壳，光效高，混光均匀，性能稳定，配一进一出手拉手1.2米长电源、信号线，1024级超高灰度调光更加柔和，
15.防护等级：电气Ⅱ级，防火V-1，防护IP20
16.声控灵敏度：65-130dB
17.工作环境：-20℃~40℃
Rated voltage: AC110V~240V, 50~60Hz
Power: 400W
Light source: 100W * 4 COB integrated light beads (can be made into single or dual color) Average lifespan: 50000H
Color temperature correction: 3200K~7200 K linear adjustment
Lens angle: 45 °
Luminous angle: can be manually adjusted
Strobe: Independent electronic strobe 1-25Hz, random strobe, pulse strobe, synchronous step strobe, monochrome, mixed color temperature strobe
Color mixing: W, Y linear color mixing, adjustable saturation from 0 to 100%
Electronic dimming: 0-100% independent electronic linear dimming, real and flickerless camera video, automatic synchronization function between master and slave, normal control of the control console, permanent synchronization of self walking
Nixie tube display menu: call various scenes, and the built-in program can be directly called for execution
Control modes: multiple voice control, DMX512, built-in program self running, master-slave online mode
Channel: 8/12 channels (two channel modes are optional)
Lamp connection: three core signal wire IN/OUT power wire IN/OUT
Features: Cast aluminum casing, high light efficiency, uniform light mixing, stable performance, equipped with a 1 meter long power and signal cable, 1024 level ultra high gray level dimming for softer lighting,
Protection level: Electrical level II, fire resistance V-1, protection Ip20
Voice control sensitivity: 65-130dB
Working environment: -20 ℃~40 ℃
Adopting a high brightness reflective cup, equipped with high brightness light beads, and equipped with a control console to adjust linear brightness function, producing precise, bright, and sharp light beams
It is equipped with digital display screen control DMX code and lamp body function selection, built-in anti-interference circuit and lamp body overtemperature protection. Its structure is perfect and compact. High speed strobe can continuously strobe 1-10 times/second. Its appearance is made of aluminum alloy, which makes it neat and bright with modern streamline design.
